- Sku:
NB-POS660P 15.6inch Windows/Android Touch POS Terminal with Printer
The NETBYE P-series POS integrated high-speed thermal printer was developed with the participation of our R&D team.
Through time and careful selection of materials, we ensured stable and reliable machine operation. Its rich I/O interfaces provide multiple connection options. Stylish design, easy maintenance, and flexible upgrade options make it the ideal choice for many applications, such as restaurants, cafes, and retail stores.
| Specification | Details |
|---|---|
| General Information | |
| Model | NB-POS660P |
| Name | 15.6-inch All in One Touch Screen POS Terminal |
| Housing | Plastic with metal combined |
| Color | Black or White |
| Display | |
| Main Screen | 15.6-inch touch screen monitor |
| Resolution | 1366 × 768 |
| Brightness | 250 cd/m² |
| View Angle | Horizon: 160°; Vertical: 150° |
| Touch Screen | Multi-point projected G+G capacitive touch |
| Sub-display | 15.6-inch display and 13.3-inch display W/ or W/o touch function, resolution 1366×768 for option |
| Customer Display | 2×20 VFD mounted to back cover for option |
| Performance - Windows Version | |
| Motherboard | Intel Celeron J4125, 2.0GHz or Intel Core I3 / I5 4th CPU for option |
| System Memory | 1×SO-DIMM DDR4 slot, support 2400MHz, 4GB (default), 8GB for option |
| Storage Device | Msata SSD 64GB or higher, up to 256GB |
| Audio | On board Real Tek ALC662 audio chip |
| LAN | 10/100Mbs, Realtek RTL8111F Lan chip |
| Wireless | Built in Mini PCI-E slot, support embedded WIFI module |
| Operating System | Windows 10/11 |
| Performance - Android Version | |
| Motherboard | Rockchip series quad core RK3568 default, RK3288, RK3399 for option |
| System Memory | On board DDRIV 2GB, 4GB for option |
| Storage Device | On board 16GB EMMC, 32GB for option |
| LAN | RJ45 port support 10/100Mbs internet |
| WIFI & BT Module | Support Wi-Fi 802.11b/g/n, BT3.0/BT4.0 support |
| Operating System | Android 7.1, up to Android 8.1 Android 11 |
| Connectivity | |
| Windows and Android (J4125 & RK3568) |
|
| Windows (J4125) |
|
| Android (RK3568) |
|
| Options | |
| 80mm Thermal Printer |
|
| 58mm Thermal Printer |
|
| MSR | Optional side MSR just for 15.6-inch |
| Web Camera | Web camera mounted on top of the display for option |
| Speaker | 8Ohm/5W speaker inside for option |
| Package | |
| Weight | Net: 6.5Kg, Gross: 8.5Kg for 15.6 dual screen |
| Package Dimensions | 300 × 465 × 500mm |
| Environment | |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -10°C to 60°C |
| Working Humidity | 10% to 80% RH |
| Storage Humidity | 10% to 90% RH |
| Accessories | |
| Power Adapter | 110-240V/50-60Hz AC power input, DC12V/5A output adaptor for W/o printer and W/ 58mm printer machine. DC12V/7A output adaptor only for W/80mm printer machine |
| Power Cable | Power cable plug compatible with USA / EU / UK etc and customized available |
| CD Driver | Motherboard driver and touch driver inside for option |
| Compliance | |
| Certifications | FCC / CE / ROHS |
